This 7-pin power entry module from JST features a current rating of 1A and a contact plating of tin and lead. It has a contact mating length of 0.094inch and a pitch of 0.059inch. The module is packaged in bulk with 1000 units per pack and is designed for through-hole mounting. It is not SVHC compliant and contains lead, making it a non-lead-free product.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the JST B7B-ZR datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
JST B7B-ZR technical specifications.
| Color | Natural |
| Contact Material | Brass, Bronze, Tin |
| Contact Mating Length | 0.094inch |
| Contact Plating | Tin, Lead |
| Contact Type | Male Pin |
| Current Rating | 1A |
| Gender | Male |
| Housing Color | Natural |
| Lead Free | Contains Lead |
| Mount | Through Hole |
| Number of Contacts | 7 |
| Number of Positions | 7 |
| Number of Rows | 1 |
| Orientation | Vertical |
| Package Quantity | 1000 |
| Packaging | Bulk |
| Pitch | 0.059inch |
| Reach SVHC Compliant | No |
| Series | ZH |
| Termination | Press-Fit |
| Test Voltage | 500V |
| RoHS | Compliant |
