Aluminum electrolytic capacitor, 1000µF capacitance, 450V DC rated voltage, 20% tolerance. Features 142mΩ ESR at 100Hz, 4.42A ripple current, and 6mA leakage current. Snap-in termination, through-hole mounting, with a 40mm diameter and 70mm height. Operates from -40°C to 85°C with an 18000-hour life expectancy.
PackageRadial
Voltage450V
Capacitance1mF
Voltage Rating450V
Quick Jump:
Technical Specifications
Kemet ALC10C102EJ450 technical specifications.
General
| Capacitance | 1mF |
| Package/Case | Radial |
| Diameter | 40mm |
| Dielectric Material | Aluminium |
| ESR (Equivalent Series Resistance) | 142mR |
| Height | 70mm |
| Height - Seated (Max) | 2.835inch |
| Impedance | 93mR |
| Lead Diameter | 2mm |
| Lead Length | 6.3mm |
| Lead Pitch | 0.886inch |
| Leakage Current | 6mA |
| Length | 70mm |
| Life (Hours) | 18000Hour |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Through Hole, PCB |
| Package Quantity | 36 |
| Packaging | Bulk |
| Ripple Current | 4.42A |
| RoHS Compliant | Yes |
| Series | ALC10 |
| Termination | Snap in |
| Test Frequency | 100Hz |
| Tolerance | 20% |
| Voltage | 450V |
| Voltage Rating | 450V |
| DC Rated Voltage | 450V |
Compliance
| RoHS | Compliant |
Datasheet
Kemet ALC10C102EJ450 Datasheet
Download the complete datasheet for Kemet ALC10C102EJ450 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
