General purpose polypropylene film capacitor with 100µF capacitance and 400V DC rating. Features 5% tolerance, 4mΩ ESR, and 32A ripple current capability. Designed for stud mount on chassis, with screw termination and a radial package. Operates across a -40°C to 85°C temperature range.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Kemet C44AFGP6100ZG0J datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Capacitance | 100uF |
| Package/Case | Radial |
| Diameter | 60mm |
| Dielectric | PP |
| Dielectric Material | PP |
| ESR (Equivalent Series Resistance) | 4mR |
| Height | 138mm |
| Height - Seated (Max) | 5.512inch |
| Lead Diameter | 6mm |
| Lead Length | 1.3mm |
| Lead Pitch | 0.878inch |
| Length | 60mm |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Stud, Chassis |
| Package Quantity | 16 |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| Ripple Current | 32A |
| RoHS Compliant | Yes |
| Series | C44A |
| Termination | Screw |
| Tolerance | 5% |
| Type | General Purpose |
| Voltage | 400V |
| Voltage Rating | 400V |
| Voltage Rating (AC) | 250V |
| DC Rated Voltage | 400V |
| RoHS | Compliant |
