The Vibra-Fit battery holder is a 2-contact device designed for through hole and PCB mounting. It is constructed from glass and liquid crystal polymer materials with bronze and tin contacts plated with tin. The holder is lead free and compliant with UL approvals. Operating temperatures range from -50°C to 145°C.
MountingThrough Hole, PCB
Quick Jump:
Technical Specifications
Keystone Electronics 1059 technical specifications.
General
| Approvals | UL |
| Body Material | Glass, Liquid Crystal Polymer |
| Contact Material | Bronze, Tin |
| Contact Plating | Tin |
| Lead Free | Lead Free |
| Material | Polymer, Liquid Crystal Polymer |
| Max Operating Temperature | 145°C |
| Min Operating Temperature | -50°C |
| Mount | Through Hole, PCB |
| Number of Batteries | 1 |
| Number of Cells | 1 |
| Number of Contacts | 2 |
| Package Quantity | 1 |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| Series | Vibra-Fit |
| Termination | PC Pin |
Compliance
| RoHS | Compliant |
Datasheet
Keystone Electronics 1059 Datasheet
Download the complete datasheet for Keystone Electronics 1059 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
