The KCG0601 is a 6R coil with a current rating of 80mA and a self-resonant frequency of 3kHz. It has a diameter of 6.6mm and a height of 3.5mm, with a lead length of 3.3mm and a lead pitch of 3.2mm. The coil is made of PPO material and has a weight of 0.34g. It is designed for through-hole mounting and has a maximum operating temperature of 60°C and a minimum operating temperature of -20°C.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Kingstate KCG0601 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Coil Resistance | 6R |
| Current Rating | 80mA |
| Diameter | 6.6mm |
| Frequency | 3kHz |
| Height | 3.5mm |
| Lead Length | 3.3mm |
| Lead Pitch | 3.2mm |
| Material | PPO |
| Max Operating Temperature | 60°C |
| Min Operating Temperature | -20°C |
| Max Supply Current | 80mA |
| Max Supply Voltage (AC) | 1.7V |
| Min Supply Voltage (AC) | 1V |
| Max Supply Voltage | 1.7V |
| Min Supply Voltage | 1V |
| Mount | Through Hole |
| Operating Supply Voltage | 1.5V |
| Outside Diameter | 6.6mm |
| Reach SVHC Compliant | No |
| Self Resonant Frequency | 3kHz |
| Termination | Pin |
| Weight | 0.34g |
| RoHS | Compliant |
