The LEM HAT500-S is a 500A current sensor module with an accuracy of 1%. It operates within a temperature range of -40°C to 105°C and has a response time of 5us. The module is designed for chassis mount and has a maximum supply current of 15mA. It is lead-free and available in a package quantity of 5, packaged in a tray.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the LEM HAT500-S datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
LEM HAT500-S technical specifications.
| Accuracy | 1% |
| Package/Case | Module |
| Current Sensing | 500A |
| Frequency | 25kHz |
| Lead Free | Lead Free |
| Linearity | 1% |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -40°C |
| Max Supply Current | 15mA |
| Mount | Chassis Mount, Base, Screw |
| Number of Channels | 1 |
| Operating Supply Voltage | 15V |
| Output Voltage | 4V |
| Overall Depth | 37mm |
| Package Quantity | 5 |
| Packaging | Tray |
| Response Time | 5us |
| Series | HAT |
| Wire/Cable Diameter | 30.5mm |
| RoHS | Compliant |
