Unidirectional TVS diode for power line protection, featuring a 36V DC rated voltage and 58.1V clamping voltage. This component offers a peak pulse power of 5kW with a maximum surge current of 86.1A. Operating across a temperature range of -55°C to 175°C, it is housed in a P package with axial termination for through-hole mounting. The diode type is ZENER, with a maximum breakdown voltage of 44.2V and a maximum power dissipation of 8W.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Littelfuse 5KP36A datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | P |
| Clamping Voltage | 58.1V |
| Clamping Voltage-Max | 58.1V |
| Diameter | 9.1mm |
| Diode Type | ZENER |
| Direction | Unidirectional |
| Lead Free | Lead Free |
| Length | 9.1mm |
| Max Breakdown Voltage | 44.2V |
| Min Breakdown Voltage | 40V |
| Max Operating Temperature | 175°C |
| Min Operating Temperature | -55°C |
| Max Power Dissipation | 8W |
| Max Surge Current | 86.1A |
| Mount | Through Hole |
| Number of Channels | 1 |
| Number of Unidirectional Channels | 1 |
| Operating Supply Voltage | 36V |
| Package Quantity | 800 |
| Packaging | Tape and Reel |
| Peak Pulse Current | 87.8A |
| Peak Pulse Power | 5kW |
| Polarity | Unidirectional |
| Power Dissipation | 5kW |
| Power Line Protection | No |
| Reach SVHC Compliant | No |
| Reverse Standoff Voltage | 36V |
| RoHS Compliant | Yes |
| Series | 5KP |
| Termination | Axial |
| DC Rated Voltage | 36V |
| Weight | 0.074075oz |
| RoHS | Compliant |
