Radial-leaded varistor for general applications, featuring a 430V varistor voltage and 275V AC voltage rating. Offers 369V DC rated voltage, 400J energy absorption, and 40kA maximum surge current. This component has a 730V clamping voltage at 200A clamping current and a capacitance of 4.5nF. Designed for through-hole mounting with a 40.5mm lead pitch and operating temperature range of -55°C to 85°C.
PackageMetal
Capacitance4.5nF
MountingSurface Mount, Chassis Mount, Bolt
Quick Jump:
Technical Specifications
Littelfuse V271DB40 technical specifications.
General
| Capacitance | 4.5nF |
| Package/Case | Metal |
| Clamping Current | 200A |
| Clamping Voltage | 730V |
| Depth | 46.8mm |
| Energy | 400J |
| Lead Free | Contains Lead |
| Lead Pitch | 40.5mm |
| Lead/Base Style | Solder |
| Length | 60.3mm |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -55°C |
| Max Surge Current | 40kA |
| Max Varistor Voltage | 473V |
| Min Varistor Voltage | 387V |
| Max Voltage Rating (AC) | 275V |
| Max Voltage Rating (DC) | 369V |
| Mount | Surface Mount, Chassis Mount, Bolt |
| Number of Circuits | 1 |
| Package Quantity | 10 |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | DB |
| Termination | Screw |
| Varistor Voltage | 430V |
| Voltage Rating (AC) | 275V |
| DC Rated Voltage | 369V |
Compliance
| RoHS | Compliant |
