The V56MT2A is a metal oxide varistor with a clamping voltage of 117V and a maximum operating temperature of 85°C. It is RoHS compliant and available in a radial, through-hole package. The varistor voltage is 56V, with a minimum varistor voltage of 44V and a maximum varistor voltage of 68V. It can handle a maximum output current of 40A and a maximum surge current of 40A.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Littelfuse V56MT2A datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Capacitance | 180pF |
| Clamping Voltage | 117V |
| Clamping Voltage-Max | 117V |
| Diameter | 3mm |
| Energy | 0.23J |
| Lead Free | Lead Free |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -55°C |
| Max Output Current | 40A |
| Max Surge Current | 40A |
| Max Varistor Voltage | 68V |
| Min Varistor Voltage | 44V |
| Mount | Radial, Through Hole |
| Number of Circuits | 1 |
| Package Quantity | 5000 |
| Packaging | Tape and Reel |
| RoHS Compliant | Yes |
| Series | MT |
| Termination | Axial |
| Varistor Voltage | 56V |
| Voltage Rating | 40V |
| Voltage Rating (AC) | 32V |
| DC Rated Voltage | 40V |
| RoHS | Compliant |
