Rotary switch featuring a 45° index angle and a 2-pole, 2-throw configuration. This electromechanical component offers a contact current rating of 4A and a general current rating of 10A, with a maximum AC voltage rating of 250V and a DC voltage rating of 12V. Constructed with silver-plated contacts and a polybutylene body, it supports panel, PCB, and through-hole mounting via PC pin terminations. Operating within a temperature range of -25°C to 85°C, this non-illuminated switch has a single deck.
Voltage Rating12V
Current Rating10A
MountingPanel, PCB, Through Hole
Quick Jump:
Technical Specifications
Lorlin RMS1130 technical specifications.
General
Contact Current Rating
4A
Contact Plating
Silver
Current Rating
10A
Depth
24mm
Height
47.8mm
Illumination Type
Illuminated
Index Angle
45°
Material
Polybutylene
Max Operating Temperature
85°C
Min Operating Temperature
-25°C
Max Voltage Rating (AC)
250V
Max Voltage Rating (DC)
12V
Mount
Panel, PCB, Through Hole
Number of Contacts
2
Number of Decks
1
Number of Poles
2
Number of Poles per Deck
2
Package Quantity
50
Reach SVHC Compliant
No
Termination
PC Pins
Throw Configuration
DP
Voltage Rating
12V
Voltage Rating (AC)
250V
DC Rated Voltage
12V
Width
17mm
Compliance
RoHS
Compliant
Datasheet
Lorlin RMS1130 Datasheet
Download the complete datasheet for Lorlin RMS1130 to view detailed technical specifications.
