The MAS806SQ is a 12V DC rated indicator from Mallory Sonalert with a current rating of 50mA. It has a maximum operating temperature of 90°C and a minimum operating temperature of -20°C. The device is designed for through hole mounting and has a diameter of 26mm. It is lead free and has a self resonant frequency of 2.8kHz. The MAS806SQ is packaged in bulk and has a weight of 10g.
Sign in to ask questions about the Mallory Sonalert MAS806SQ datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Mallory Sonalert MAS806SQ technical specifications.
| Color | Grey |
| Current Rating | 50mA |
| Diameter | 26mm |
| Frequency | 2.8kHz |
| Height | 22mm |
| Input Type | DC |
| Lead Free | Lead Free |
| Max Operating Temperature | 90°C |
| Min Operating Temperature | -20°C |
| Max Supply Voltage | 14V |
| Min Supply Voltage | 6V |
| Mount | Through Hole, Flush |
| Operating Supply Current | 50mA |
| Outside Diameter | 26mm |
| Packaging | Bulk |
| Self Resonant Frequency | 2.8kHz |
| Series | MAS |
| Termination | PC Pins |
| Voltage Rating | 12V |
| DC Rated Voltage | 12V |
| Weight | 10g |
| RoHS | Compliant |
