Mallory Sonalert
SC628AJR
Audio Indicator Piezo 6VDC/6VAC 28VDC/28VAC 16mA 68dBA 2400Hz to 3400Hz Panel Mount Screw Bulk
Frequency2.9kHz
Current Rating16mA
MountingPanel, Flush
Quick Jump:
Technical Specifications
Mallory Sonalert SC628AJR technical specifications.
General
Current Rating
16mA
Diameter
43mm
Frequency
2.9kHz
Height
48.51mm
Max Operating Temperature
65°C
Min Operating Temperature
-30°C
Max Supply Current
16mA
Mount
Panel, Flush
Operating Supply Current
23mA
Operating Supply Voltage
28V
Packaging
Bulk
Self Resonant Frequency
2.9kHz
Series
SC
Termination
Screw
DC Rated Voltage
6V
Washable
No
Compliance
RoHS
Compliant
Datasheet
Mallory Sonalert SC628AJR Datasheet
Download the complete datasheet for Mallory Sonalert SC628AJR to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
