The DG406CJ+ is a single 1-channel logic demultiplexer with a maximum dual supply voltage of 20V and a minimum dual supply voltage of 4.5V. It operates over a temperature range of 0°C to 70°C and has a maximum power dissipation of 727mW. The device is packaged in a lead-free PDIP package and is RoHS compliant. It has a propagation delay of 300ns and an operating supply current of 500uA.
Sign in to ask questions about the Maxim DG406CJ+ datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Maxim DG406CJ+ technical specifications.
| Package/Case | PDIP |
| Lead Free | Lead Free |
| Max Dual Supply Voltage | 20V |
| Min Dual Supply Voltage | 4.5V |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | 0°C |
| Max Power Dissipation | 727mW |
| Max Supply Voltage | 30V |
| Min Supply Voltage | 5V |
| Mount | Through Hole |
| Number of Channels | 1 |
| Number of Circuits | 1 |
| Number of Switches | 1 |
| Operating Supply Current | 500uA |
| Operating Supply Voltage | 28V |
| Package Quantity | 14 |
| Packaging | Rail/Tube |
| Propagation Delay | 300ns |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| RoHS | Compliant |
Download the complete datasheet for Maxim DG406CJ+ to view detailed technical specifications.
