Maxim MAX16803ATE/V+T technical specifications.
| Package/Case | SOT-23 |
| High Level Output Current | 350mA |
| Low Level Output Current | 35mA |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Power Dissipation | 571mW |
| Max Reset Threshold Voltage | 4.699V |
| Min Reset Threshold Voltage | 4.561V |
| Max Supply Current | 1.4mA |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 1V |
| Mount | Surface Mount |
| Number of Outputs | 1 |
| Package Quantity | 2500 |
| Packaging | Tape and Reel |
| Power Dissipation | 2.6667W |
| RoHS Compliant | Yes |
| Series | MAX16803 |
| Watchdog Timer | No |
| RoHS | Compliant |
