Digital temperature sensor with I2C, SMBus, and 2-Wire interface. Operates across a wide temperature range from -55°C to 150°C. Features a 16-bit resolution and a supply voltage range of 2.5V to 3.7V. Packaged in an 8-pin TDFN and supplied on tape and reel. RoHS compliant.
Quick Jump:
Technical Specifications
Maxim MAX31725MTA+T technical specifications.
General
| Interface | I2C, SMBus, 2-Wire |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -55°C |
| Max Supply Voltage (DC) | 3.7V |
| Min Supply Voltage (DC) | 2.5V |
| Operating Supply Voltage | 3.7V |
| Output Type | Digital, I2C |
| Package Quantity | 2500 |
| Packaging | Tape and Reel |
| Resolution | 16b |
| RoHS Compliant | Yes |
Compliance
| RoHS | Compliant |
Datasheet
Maxim MAX31725MTA+T Datasheet
Download the complete datasheet for Maxim MAX31725MTA+T to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
