8x1 Multiplexer IC, SOIC package, featuring a 1500ns propagation delay and 3.5kR on-state resistance. Operates with single or dual supplies from 5V to 18V, consuming a low 4.5uA operating supply current. This surface mount component offers a maximum power dissipation of 750mW and is RoHS compliant, suitable for operation between 0°C and 70°C.
Sign in to ask questions about the Maxim MAX328CWE+ datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Maxim MAX328CWE+ technical specifications.
| Package/Case | SOIC |
| Height | 2.35mm |
| Lead Free | Lead Free |
| Length | 10.5mm |
| Logic Function | Multiplexer |
| Max Dual Supply Voltage | 18V |
| Min Dual Supply Voltage | 5V |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | 0°C |
| Max Power Dissipation | 750mW |
| Max Supply Voltage | 18V |
| Min Supply Voltage | 5V |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Number of Circuits | 1 |
| Number of Switches | 1 |
| On-State Resistance | 3.5kR |
| Operating Supply Current | 4.5uA |
| Package Quantity | 46 |
| Packaging | Rail/Tube |
| Propagation Delay | 1500ns |
| Radiation Hardening | No |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Supply Current | 4.5uA |
| Supply Type | Single, Dual |
| Termination | SMD/SMT |
| Throw Configuration | DPST |
| Width | 7.6mm |
| RoHS | Compliant |
