High-precision current sense amplifier with a 76V maximum supply voltage and 20V/V gain. Features a 250kHz bandwidth, 100dB common mode rejection ratio, and low 5µA input bias current. Operating supply current is 75µA, with a maximum of 190µA. Housed in a compact UMAX package, this single-channel amplifier operates from 4.5V to 76V and offers a wide temperature range of -40°C to 125°C.
Sign in to ask questions about the Maxim MAX4080TAUA+ datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Maxim MAX4080TAUA+ technical specifications.
| -3db Bandwidth | 250kHz |
| Bandwidth | 250kHz |
| Package/Case | UMAX |
| Common Mode Rejection Ratio | 100dB |
| Height | 0.95mm |
| Input Bias Current | 5uA |
| Input Offset Voltage (Vos) | 100uV |
| Length | 3.1mm |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Supply Current | 190uA |
| Max Supply Voltage | 76V |
| Min Supply Voltage | 4.5V |
| Number of Amplifiers | 1 |
| Number of Channels | 1 |
| Number of Circuits | 1 |
| Operating Supply Current | 75uA |
| Package Quantity | 50 |
| Packaging | Rail/Tube |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Supply Current | 75uA |
| Width | 3.1mm |
| RoHS | Compliant |
Download the complete datasheet for Maxim MAX4080TAUA+ to view detailed technical specifications.
