The MAX4614EUD is a 4-bit SPST single supply surface mount multiplexer from Maxim. It operates over a temperature range of -40°C to 85°C and has a maximum supply voltage of 5.5V. The device is available in a TSSOP-14 package and is not RoHS compliant due to containing lead. The MAX4614EUD has an on-state resistance of 10R and an operating supply current of 1uA.
Sign in to ask questions about the Maxim MAX4614EUD datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Maxim MAX4614EUD technical specifications.
| Package/Case | TSSOP |
| Lead Free | Contains Lead |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 2V |
| Mount | Surface Mount |
| Number of Bits | 4 |
| On-State Resistance | 10R |
| Operating Supply Current | 1uA |
| Package Quantity | 96 |
| Packaging | Rail/Tube |
| Radiation Hardening | No |
| RoHS Compliant | No |
| Supply Type | Single |
| Throw Configuration | SPST |
| RoHS | Not CompliantNo |
