The MAX4846ELT-T is an industrial-grade power management IC with a maximum operating temperature of 85 degrees Celsius and a minimum operating temperature of -40 degrees Celsius. It has a 6-pin package with a width of 1mm and a length of 1.5mm. The device operates on a supply voltage between 1.2V and 28V and has a single function. It is available in a VSON package type.
Quick Jump:
Technical Specifications
Maxim MAX4846ELT-T technical specifications.
General
| Max Operating Temperature | 85 |
| Number of Terminals | 6 |
| Min Operating Temperature | -40 |
| Terminal Position | DUAL |
| JEDEC Package Code | R-XDSO-N6 |
| Width | 1 |
| Length | 1.5 |
| Pin Count | 6 |
| Number of Functions | 1 |
| Temperature Grade | INDUSTRIAL |
| Supply Voltage-Nom (Vsup) | 4 |
| Supply Voltage-Max (Vsup) | 28 |
| Supply Voltage-Min (Vsup) | 1.2 |
| Number of Channels | 1 |
Compliance
| RoHS | No |
| Eccn Code | EAR99 |
| Lead Free | No |
| HTS Code | 8542.39.00.01 |
| REACH | Compliant |
| Military Spec | False |
Datasheet
Maxim MAX4846ELT-T Datasheet
Download the complete datasheet for Maxim MAX4846ELT-T to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
