16-output LED driver IC with 32 segments, delivering up to 55mA output current per channel. Features a 3V to 5.5V operating supply voltage range and a maximum input voltage of 5.5V. This surface-mount component is housed in a 24-TSSOP package with dimensions of 7.9mm length, 4.5mm width, and 0.95mm height. It operates efficiently with a maximum supply current of 25mA and a power dissipation of 975mW, suitable for applications within a -40°C to 125°C temperature range. RoHS compliant and lead-free.
PackageTSSOP
MountingSurface Mount
Power975mW
Quick Jump:
Technical Specifications
Maxim MAX6969AUG+ technical specifications.
General
Package/Case
TSSOP
Height
0.95mm
Lead Free
Lead Free
Length
7.9mm
Low Level Output Current
60mA
Max Input Voltage
5.5V
Min Input Voltage
3V
Max Operating Temperature
125°C
Min Operating Temperature
-40°C
Max Power Dissipation
975mW
Max Supply Current
25mA
Mount
Surface Mount
Number of Outputs
16
Number of Segments
32
Operating Supply Voltage
5.5V
Output Current
55mA
Output Voltage
5.5V
Package Quantity
62
Packaging
Rail/Tube
Power Dissipation
975mW
Radiation Hardening
No
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Width
4.5mm
Compliance
RoHS
Compliant
Datasheet
Maxim MAX6969AUG+ Datasheet
Download the complete datasheet for Maxim MAX6969AUG+ to view detailed technical specifications.
