Technical Specifications
Maxim MAX9612AUB+ technical specifications.
General
| Bandwidth | 2.5MHz |
| Package/Case | UMAX |
| Common Mode Rejection Ratio | 100dB |
| Input Bias Current | 1uA |
| Input Offset Voltage (Vos) | 350uV |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 2.7V |
| Number of Amplifiers | 1 |
| Output Current | 15mA |
| Output Current per Channel | 15mA |
| Package Quantity | 50 |
| Packaging | Rail/Tube |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Supply Current | 1.6mA |
Compliance
| RoHS | Compliant |
Datasheet
Maxim MAX9612AUB+ Datasheet
Download the complete datasheet for Maxim MAX9612AUB+ to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
