PackageDO-214AC
MountingSurface Mount
Quick Jump:
Technical Specifications
MCC SS210-TP technical specifications.
General
Average Rectified Current
2A
Package/Case
DO-214AC
Forward Current
2A
Lead Free
Lead Free
Max Forward Surge Current (Ifsm)
50A
Max Operating Temperature
125°C
Min Operating Temperature
-55°C
Max Repetitive Reverse Voltage (Vrrm)
100V
Max Reverse Leakage Current
500uA
Max Reverse Voltage (DC)
100V
Max Surge Current
50A
Mount
Surface Mount
Package Quantity
1
Packaging
Tape and Reel
Peak Non-Repetitive Surge Current
50A
Radiation Hardening
No
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Compliance
RoHS
Compliant
Datasheet
MCC SS210-TP Datasheet
Download the complete datasheet for MCC SS210-TP to view detailed technical specifications.
