Single output 30W AC-DC medical power supply, featuring a 5V output voltage and 6A maximum output current. This external wall adapter offers universal input voltage, a fixed output type, and operates efficiently at 81.5%. Designed for desktop mounting, it boasts a wide operating temperature range from -30°C to 60°C.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Mean Well GSM60A05-P1J datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Mean Well GSM60A05-P1J technical specifications.
| Package/Case | 100 |
| Current - Output 1 | 6A |
| Efficiency | 81.5% |
| Height | 1.2inch |
| Length | 4.9inch |
| Max Input Current | 1.4A |
| Max Operating Temperature | 60°C |
| Min Operating Temperature | -30°C |
| Max Output Current | 6A |
| Max Output Power | 30W |
| Mount | Desktop |
| Number of Outputs | 1 |
| Output Current | 6A |
| Output Power | 30W |
| Output Type | Fixed |
| Output Voltage | 5V |
| Overall Depth | 31.5mm |
| Package Quantity | 40 |
| Packaging | Bulk |
| Polarity | Positive |
| Regulator Type | UNIVERSAL |
| Voltage - Output 1 | 5V |
| Weight | 11.287668oz |
| Width | 2inch |
| RoHS | Compliant |
Download the complete datasheet for Mean Well GSM60A05-P1J to view detailed technical specifications.
