AC/DC LED Power Supply, 21W, Constant Current, Single Output. Delivers 700mA output current with a voltage range of 9V to 30V. Features 90-264V AC input, 83% efficiency, and a maximum output power of 21W. Operates within a wide temperature range of -30°C to 70°C. IP67 rated for robust environmental protection. Panel or screw mounting options available.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Mean Well LPC-20-700 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Mean Well LPC-20-700 technical specifications.
| Approvals | UL |
| Current - Output 1 | 700mA |
| Current Rating | 700mA |
| Depth | 35mm |
| Efficiency | 83% |
| Height | 26mm |
| Lead Free | Lead Free |
| Length | 118mm |
| Max Input Current | 550mA |
| Max Input Voltage | 264V |
| Min Input Voltage | 90V |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -30°C |
| Max Output Current | 700mA |
| Max Output Power | 21W |
| Max Output Voltage | 30V |
| Min Output Voltage | 9V |
| Mount | Panel, Screw |
| Number of Channels | 1 |
| Number of Outputs | 1 |
| Output Current | 700mA |
| Output Power | 21W |
| Output Voltage | 30V |
| Radiation Hardening | No |
| Ratings | IP67 |
| Reach SVHC Compliant | Unknown |
| Series | LPC-20 |
| Voltage - Output 1 | 30V |
| Width | 35mm |
| RoHS | Compliant |
