60W AC/DC LED power supply, constant voltage, single output. Delivers 2.5A output current at a nominal 24V, with a maximum output voltage of 24V. Features a wide input voltage range of 90-305V AC and operates efficiently at 89%. Designed for panel or screw mounting, this white, IP67 rated power supply offers a broad operating temperature range from -40°C to 70°C.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Mean Well LPF-60-24 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Mean Well LPF-60-24 technical specifications.
| Color | White |
| Current - Output 1 | 2.5A |
| Depth | 32mm |
| Efficiency | 89% |
| Height | 32mm |
| Lead Free | Lead Free |
| Length | 162.5mm |
| Max Input Current | 800mA |
| Max Input Voltage | 305V |
| Min Input Voltage | 90V |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -40°C |
| Max Output Power | 60W |
| Max Output Voltage | 24V |
| Mount | Panel, Screw |
| Nominal Output Voltage | 24V |
| Number of Channels | 1 |
| Number of Outputs | 1 |
| Output Current | 2.5A |
| Output Power | 60W |
| Output Voltage | 24V |
| Ratings | IP67 |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | LPF-60 |
| Voltage - Output 1 | 24V |
| Weight | 450g |
| Width | 43mm |
| RoHS | Compliant |
