102W AC/DC LED power supply, constant voltage output at 12V with a single channel and 8.5A output current. Features a wide input voltage range of 90-264V AC and an efficiency of 85%. Operating temperature range from -25°C to 70°C, with IP67 rating for environmental protection. Dimensions are 190mm length, 52mm width, and 37mm depth, utilizing screw mounting and cable termination. RoHS compliant and lead-free construction.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Mean Well LPV-100-12 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Mean Well LPV-100-12 technical specifications.
| Current - Output 1 | 8.5A |
| Depth | 37mm |
| Efficiency | 85% |
| Height | 37mm |
| Lead Free | Lead Free |
| Length | 190mm |
| Max Input Current | 2.2A |
| Max Input Voltage | 264V |
| Min Input Voltage | 90V |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -25°C |
| Max Output Power | 102W |
| Max Output Voltage | 12V |
| Mount | Screw |
| Nominal Output Voltage | 12V |
| Number of Channels | 1 |
| Number of Outputs | 1 |
| Output Current | 8.5A |
| Output Power | 102W |
| Output Voltage | 12V |
| Ratings | IP67 |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | LPV-100 |
| Termination | Cable |
| Voltage - Output 1 | 12V |
| Weight | 1.389lb |
| Width | 52mm |
| RoHS | Compliant |
