AC/DC LED Power Supply, 100.8W, single output, constant voltage/constant current. Features 24V nominal output voltage and 4.2A output current. Operates with a wide input voltage range of 90-264V AC and achieves 88% efficiency. Designed for demanding environments with IP67 rating and a broad operating temperature range of -25°C to 70°C. Screw mount termination with cable leads.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Mean Well LPV-100-24 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Mean Well LPV-100-24 technical specifications.
| Current - Output 1 | 4.2A |
| Depth | 37mm |
| Efficiency | 88% |
| Height | 37mm |
| Lead Free | Lead Free |
| Length | 190mm |
| Max Input Current | 2.2A |
| Max Input Voltage | 264V |
| Min Input Voltage | 90V |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -25°C |
| Max Output Power | 100.8W |
| Max Output Voltage | 24V |
| Mount | Screw |
| Nominal Output Voltage | 24V |
| Number of Channels | 1 |
| Number of Outputs | 1 |
| Output Current | 4.2A |
| Output Power | 100.8W |
| Output Voltage | 24V |
| Ratings | IP67 |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | LPV-100 |
| Termination | Cable |
| Voltage - Output 1 | 24V |
| Weight | 1.389lb |
| Width | 52mm |
| RoHS | Compliant |
