This DC/DC converter from Mean Well has a single output of 5V with a maximum current rating of 4.4A and a maximum output power of 22W. It operates with 75% efficiency and is approved to UL, IEC, and EN standards. The device is mounted on a PCB or screw and has a compact size of 89mm in length, 51mm in width, and 19.3mm in height. It can withstand operating temperatures between -20°C and 60°C.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Mean Well NFM-20-5 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Mean Well NFM-20-5 technical specifications.
| Approvals | UL, IEC, EN |
| Current - Output 1 | 4.4A |
| Depth | 19.3mm |
| Efficiency | 75% |
| Height | 19.3mm |
| Lead Free | Lead Free |
| Length | 89mm |
| Max Current Rating | 600mA |
| Max Operating Temperature | 60°C |
| Min Operating Temperature | -20°C |
| Max Output Power | 22W |
| Mount | PCB, Screw |
| Number of Outputs | 1 |
| Output Current | 4.4A |
| Output Power | 22W |
| Output Voltage | 5V |
| Package Quantity | 105 |
| RoHS Compliant | Yes |
| Series | NFM-20 |
| Voltage - Output 1 | 5V |
| Weight | 0.09kg |
| Width | 51mm |
| RoHS | Compliant |
Download the complete datasheet for Mean Well NFM-20-5 to view detailed technical specifications.
