The Mean Well PCD-25-1050B is an enclosed AC/DC power supply with a single 24V output. It has a maximum output power of 25.2W and a maximum output current of 1.05A. The supply is designed for panel mount applications and operates within a temperature range of -30°C to 60°C. It is compliant with RoHS regulations and has a high efficiency of 80.5%.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Mean Well PCD-25-1050B datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Color | White |
| Current - Output 1 | 1.05A |
| Efficiency | 80.5% |
| Height | 1.16inch |
| Length | 3.3inch |
| Max Input Current | 600mA |
| Max Operating Temperature | 60°C |
| Min Operating Temperature | -30°C |
| Max Output Power | 25.2W |
| Mount | Panel, Screw |
| Number of Outputs | 1 |
| Output Current | 1.05A |
| Output Power | 25.2W |
| RoHS Compliant | Yes |
| Series | PCD-25 |
| Voltage - Output 1 | 24V |
| Voltage Rating | 295V |
| Weight | 190g |
| Width | 2.24inch |
| RoHS | Compliant |
