12V DC/DC converter module delivering 21.6W output power and 1.8A output current. Features a wide AC input voltage range of 90-264V with a maximum input current of 600mA. Operates efficiently at 81% and is housed in a black, lead-free module package suitable for PCB through-hole mounting. Approvals include UL, TUV, IEC, and EN, with a temperature range of -20°C to 60°C.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Mean Well PM-20-12 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Approvals | UL, TUV, IEC, EN |
| Package/Case | Module |
| Color | Black |
| Current - Output 1 | 1.8A |
| Efficiency | 81% |
| Height | 22.7mm |
| Lead Free | Lead Free |
| Length | 94mm |
| Max Input Current | 600mA |
| Max Input Voltage (AC) | 264V |
| Min Input Voltage (AC) | 90V |
| Max Operating Temperature | 60°C |
| Min Operating Temperature | -20°C |
| Max Output Current | 1.8A |
| Max Output Power | 21.6W |
| Mount | Through Hole, PCB |
| Number of Outputs | 1 |
| Output Current | 1.8A |
| Output Power | 22W |
| Output Voltage | 12V |
| Package Quantity | 90 |
| RoHS Compliant | Yes |
| Series | PM-20 |
| Voltage - Output 1 | 12V |
| Weight | 191.11g |
| Width | 56mm |
| RoHS | Compliant |
