24V DC/DC converter module, delivering 22.08W output power with 920mA maximum output current. Features a 90-264V AC input range and 84% efficiency. Designed for through-hole PCB mounting, this black, lead-free module operates from -20°C to 60°C and is UL, TUV, IEC, and EN approved.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Mean Well PM-20-24 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Approvals | UL, TUV, IEC, EN |
| Package/Case | Module |
| Color | Black |
| Current - Output 1 | 920mA |
| Depth | 56mm |
| Efficiency | 84% |
| Height | 22.7mm |
| Lead Free | Lead Free |
| Length | 94mm |
| Max Input Current | 600mA |
| Max Input Voltage (AC) | 264V |
| Min Input Voltage (AC) | 90V |
| Max Operating Temperature | 60°C |
| Min Operating Temperature | -20°C |
| Max Output Current | 920mA |
| Max Output Power | 22.08W |
| Mount | Through Hole, PCB |
| Number of Outputs | 1 |
| Output Current | 920mA |
| Output Power | 22.08W |
| Output Voltage | 24V |
| Package Quantity | 90 |
| RoHS Compliant | Yes |
| Series | PM-20 |
| Voltage - Output 1 | 24V |
| Weight | 191.11g |
| Width | 56mm |
| RoHS | Compliant |
