16Kb Serial EEPROM memory IC, organized as 2K x 8, featuring a 1-Wire interface and a maximum operating frequency of 100kHz. This surface-mount component is housed in a compact SOT-23 package with tin-matte contact plating. It operates within a supply voltage range of 2.5V to 5.5V, with a typical operating voltage of 5V, and offers write protection. The device is RoHS compliant and suitable for operation across a temperature range of -40°C to 85°C.
Frequency100kHz
PackageSOT-23
Current5mA
MountingSurface Mount
Quick Jump:
Technical Specifications
Microchip 11LC160T-I/TT technical specifications.
General
| Package/Case | SOT-23 |
| Contact Plating | Tin, Matte |
| Density | 16Kb |
| Frequency | 100kHz |
| Height | 0.95mm |
| Interface | Serial |
| Lead Free | Lead Free |
| Length | 2.9mm |
| Max Frequency | 100kHz |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 5.5V |
| Memory Size | 16Kb |
| Memory Type | EEPROM, |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.5V |
| Mount | Surface Mount |
| Operating Supply Voltage | 5V |
| Organization | 2KX8 |
| Package Quantity | 3000 |
| Packaging | Tape and Reel |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Supply Current | 5mA |
| Termination | SMD/SMT |
| Width | 1.3mm |
| Write Protection | YES |
Compliance
| RoHS | Compliant |
Datasheet
Microchip 11LC160T-I/TT Datasheet
Download the complete datasheet for Microchip 11LC160T-I/TT to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
