4Kb I2C/2-Wire Serial EEPROM, organized as 256 x 8, features a 400kHz maximum frequency and 900ns access time. This surface mount device, housed in a SOT-23 package with tin/matte plating, operates from 2.5V to 5.5V supply voltage. It offers 5ms maximum write cycle time and includes write protection. The component is RoHS compliant and suitable for operation between -40°C and 85°C.
Frequency400kHz
PackageSOT-23
Current3mA
MountingSurface Mount
Quick Jump:
Technical Specifications
Microchip 24LC04BT-I/OT technical specifications.
General
Access Time
900ns
Access Time-Max
900ns
Package/Case
SOT-23
Contact Plating
Tin, Matte
Density
4Kb
Frequency
400kHz
Height
1.3mm
Interface
I2C, Serial
Lead Free
Lead Free
Length
3.1mm
Max Frequency
400kHz
Max Operating Temperature
85°C
Max Supply Voltage
5.5V
Memory Size
4Kb
Memory Type
EEPROM,
Min Operating Temperature
-40°C
Min Supply Voltage
2.5V
Mount
Surface Mount
Organization
256 x 8
Package Quantity
3000
Packaging
Tape and Reel
Programming Voltage
5.5V
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Supply Current
3mA
Supply Voltage-Nom
5.5V
Termination
SMD/SMT
Width
1.8mm
Write Cycle Time-Max (tWC)
5ms
Write Protection
YES
Compliance
RoHS
Compliant
