4Kb SPI bus serial EEPROM with 512 x 8 organization. Features 50ns access time and a maximum operating frequency of 10MHz. Operates from 2.5V to 5.5V supply voltage, with a nominal 5V. Packaged in a lead-free, RoHS compliant MSOP-8 surface mount package. Includes write protection and a write cycle time of 5ms.
Frequency10MHz
PackageMSOP
Current5mA
MountingSurface Mount
Quick Jump:
Technical Specifications
Microchip 25LC040A-I/MS technical specifications.
General
| Access Time | 50ns |
| Access Time-Max | 50ns |
| Package/Case | MSOP |
| Density | 4Kb |
| Frequency | 10MHz |
| Height | 0.95mm |
| Interface | SPI, Serial |
| Lead Free | Lead Free |
| Length | 3mm |
| Max Frequency | 10MHz |
| Max Operating Temperature | 85°C |
| Memory Size | 4Kb |
| Memory Type | EEPROM, |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 2.5V |
| Mount | Surface Mount |
| Number of Words | 512 |
| Operating Supply Voltage | 5V |
| Organization | 512X8 |
| Package Quantity | 100 |
| Packaging | Rail/Tube |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Supply Current | 5mA |
| Supply Voltage-Nom | 5.5V |
| Termination | SMD/SMT |
| Width | 3mm |
| Write Cycle Time-Max (tWC) | 5ms |
| Write Protection | YES |
Compliance
| RoHS | Compliant |
Datasheet
Microchip 25LC040A-I/MS Datasheet
Download the complete datasheet for Microchip 25LC040A-I/MS to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
