32-bit AVR microcontroller featuring 512KB FLASH memory and 64KB RAM. Operates at up to 66MHz with a 3V to 5.5V supply voltage. Offers 16 ADC channels, 4 PWM channels, and extensive interfaces including I2C, SPI, USB, CAN, Ethernet, IrDA, UART, USART, and LIN. This surface-mount TQFP package component includes peripherals like DMA, POR, and WDT.
Frequency66MHz
PackageTQFP
MountingSurface Mount
Quick Jump:
Technical Specifications
Microchip AT32UC3C2512C-A2UT technical specifications.
General
Package/Case
TQFP
Core Architecture
AVR
Data Bus Width
32b
Frequency
66MHz
Height
1.05mm
Interface
I2C, SPI, USB, CAN, Ethernet, IrDA, UART, USART, LIN
Length
10mm
Max Frequency
66MHz
Max Operating Temperature
85°C
Max Supply Voltage
5.5V
Memory Size
512KB
Memory Type
FLASH,
Min Operating Temperature
-40°C
Min Supply Voltage
3V
Mount
Surface Mount
Number of ADC Channels
16
Number of Ethernet Channels
1
Number of I/Os
45
Number of I2C Channels
2
Number of PWM Channels
4
Number of SPI Channels
2
Number of Timers/Counters
4
Operating Supply Voltage
5V
Oscillator Type
Internal
Packaging
Tray
Peripherals
Brown-out Detect/Reset, POR, PWM, WDT, DMA
Radiation Hardening
No
RAM Size
64KB
Reach SVHC Compliant
No
RoHS Compliant
No
Width
10mm
Compliance
RoHS
Not CompliantNo
Datasheet
Microchip AT32UC3C2512C-A2UT Datasheet
Download the complete datasheet for Microchip AT32UC3C2512C-A2UT to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
