Surface mount supervisory circuit with a 2.93V threshold voltage, featuring active low reset. Monitors a single voltage with a reset timeout of 80ms. Operates from 1V to 5.5V supply voltage, drawing a maximum of 20uA supply current. Packaged in a 3-pin SOT-23-3, measuring 2.92mm x 1.3mm x 0.95mm, with a maximum operating temperature of 125°C.
PackageSOT-23-3
Current20uA
MountingSurface Mount
Quick Jump:
Technical Specifications
Microchip MCP121T-300E/TT technical specifications.
General
| Package/Case | SOT-23-3 |
| Height | 0.95mm |
| Lead Free | Lead Free |
| Length | 2.92mm |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Reset Threshold Voltage | 2.974V |
| Min Reset Threshold Voltage | 2.866V |
| Max Supply Current | 20uA |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 1V |
| Mount | Surface Mount |
| Number of Elements | 1 |
| Number of Voltages Monitored | 1 |
| Operating Supply Current | 20uA |
| Overvoltage Threshold | 2.974V |
| Package Quantity | 3000 |
| Packaging | Cut Tape |
| Quiescent Current | 1uA |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| Reset | Active Low |
| Reset Timeout | 80ms |
| RoHS Compliant | Yes |
| Supply Current | 20uA |
| Threshold Voltage | 2.93V |
| Type | Simple Reset/Power-On Reset |
| Undervoltage Threshold | 2.866V |
| Watchdog Timer | No |
| Width | 1.3mm |
Compliance
| RoHS | Compliant |
Datasheet
Microchip MCP121T-300E/TT Datasheet
Download the complete datasheet for Microchip MCP121T-300E/TT to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
