Automotive-grade charge pump IC featuring a 1.2MHz switching frequency, capable of generating a fixed 3.3V or 5V output from a 2V to 5.5V input range. This surface-mount component delivers up to 150mA output current and operates across an extended temperature range of -40°C to 85°C. Housed in an 8-pin MSOP package, it supports a maximum supply voltage of 5.5V and is RoHS compliant.
PackageMSOP
Current Rating80A
MountingSurface Mount
Quick Jump:
Technical Specifications
Microchip MCP1253-33X50I/MS technical specifications.
General
| Package/Case | MSOP |
| Current Rating | 80A |
| Height | 0.85mm |
| Lead Free | Lead Free |
| Length | 3mm |
| Max Input Voltage | 5.5V |
| Min Input Voltage | 2V |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 120mA |
| Min Output Voltage | 5V |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 2.1V |
| Mount | Surface Mount |
| Nominal Output Voltage | 3.3V |
| Number of Outputs | 1 |
| Output Configuration | Positive |
| Output Current | 150mA |
| Output Type | Fixed |
| Output Voltage | 5V |
| Packaging | Rail/Tube |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Switching Frequency-Max | 1.2MHz |
| Synchronous Rectifier | No |
| Topology | Charge Pump |
| Weight | 0.004938oz |
| Width | 3mm |
