Adjustable positive LDO regulator offering 1A output current with a 0.4V dropout voltage. Features a 2% accuracy and an adjustable output voltage range from 0.8V to 5V. Operates with a maximum input voltage of 6V and a minimum of 2.3V, across an extended temperature range of -40°C to 125°C. This surface mount component is housed in a D2PAK package, designed for efficient power management.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Microchip MCP1826-ADJE/ET datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Microchip MCP1826-ADJE/ET technical specifications.
| Accuracy | 2% |
| Package/Case | D2PAK |
| Dropout Voltage | 250mV |
| Height | 4.83mm |
| Input Bias Current | 120uA |
| Lead Free | Lead Free |
| Length | 10.67mm |
| Max Input Voltage | 6V |
| Min Input Voltage | 2.3V |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 1A |
| Min Output Voltage | 800mV |
| Mount | Surface Mount |
| Number of Outputs | 1 |
| Output Current | 1A |
| Output Type | Adjustable |
| Output Voltage | 5V |
| Package Quantity | 50 |
| Packaging | Rail/Tube |
| Polarity | Positive |
| Power Dissipation | 2.083W |
| Quiescent Current | 220uA |
| Radiation Hardening | No |
| Reference Voltage | 410mV |
| RoHS Compliant | Yes |
| Width | 9.65mm |
| RoHS | Compliant |
