The MCP23018-E/SP is a 16-bit I2C/SPI I/O expander with 16 I/Os and an output current of 25mA. It operates over a temperature range of -40°C to 125°C and is packaged in a DIP-20 package. The device is RoHS compliant and has a maximum power dissipation of 700mW. It can be used to expand the number of I/Os in a system and can operate at a maximum frequency of 3.4MHz.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Microchip MCP23018-E/SP datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | DIP |
| Frequency | 3.4MHz |
| Interface | I2C, Serial |
| Lead Free | Lead Free |
| Max Frequency | 3.4MHz |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 1.8V |
| Mount | Through Hole |
| Number of Channels | 1 |
| Number of I/Os | 16 |
| Output Current | 25mA |
| Package Quantity | 15 |
| Packaging | Rail/Tube |
| Power Dissipation | 700mW |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Supply Current | 1mA |
| Supply Voltage-Nom | 5.5V |
| RoHS | Compliant |
Download the complete datasheet for Microchip MCP23018-E/SP to view detailed technical specifications.
