16-bit I/O Expander with SPI and I2C serial interfaces. Operates at frequencies up to 10MHz with a maximum supply voltage of 5.5V and a minimum of 1.8V. Features 16 configurable I/O pins, surface mountable in a QFN package, and supports a wide operating temperature range from -40°C to 125°C. This RoHS compliant component offers 400mA output current and 700mW power dissipation.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Microchip MCP23S18-E/MJ datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Microchip MCP23S18-E/MJ technical specifications.
| Package/Case | QFN |
| Frequency | 10MHz |
| Interface | SPI, I2C, Serial |
| Lead Free | Lead Free |
| Max Frequency | 3.4MHz |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Power Dissipation | 700mW |
| Max Supply Voltage | 5.5V |
| Min Supply Voltage | 1.8V |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Number of I/Os | 16 |
| Output Current | 400mA |
| Packaging | Rail/Tube |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Supply Current | 1mA |
| Supply Voltage-Nom | 5.5V |
| Weight | 0.032741oz |
| RoHS | Compliant |
