PackageQFN
Current600uA
Resistance5kR
MountingSurface Mount
Quick Jump:
Technical Specifications
Microchip MCP4441T-502E/ML technical specifications.
General
Package/Case
QFN
Interface
I2C, Serial, 2-Wire
Max Operating Temperature
125°C
Max Supply Voltage
5.5V
Memory Type
Non-Volatile,
Min Operating Temperature
-40°C
Min Supply Voltage
2.7V
Mount
Surface Mount
Number of Circuits
4
Number of Elements
4
Number of Positions
128
Number of Taps
129
Package Quantity
3300
Packaging
Tape and Reel
Radiation Hardening
No
Resistance
5kR
RoHS Compliant
Yes
Series
WiperLock™
Supply Current
600uA
Taper
Linear
Tolerance
20%
Compliance
RoHS
Compliant
Datasheet
Microchip MCP4441T-502E/ML Datasheet
Download the complete datasheet for Microchip MCP4441T-502E/ML to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
