PackageSOT-23-5
MountingSurface Mount
Quick Jump:
Technical Specifications
Microchip MIC5318-3.3YD5-TR technical specifications.
General
Accuracy
2%
Package/Case
SOT-23-5
Height
0.87mm
Lead Free
Lead Free
Length
2.9mm
Max Input Voltage
6V
Min Input Voltage
2.3V
Max Operating Temperature
125°C
Min Operating Temperature
-40°C
Max Output Current
300mA
Min Output Voltage
3.3V
Mount
Surface Mount
Number of Outputs
1
Number of Regulators
1
Output Configuration
Positive
Output Current
300mA
Output Type
Fixed
Output Voltage
3.3V
Packaging
Tape and Reel
Power Supply Rejection Ratio (PSRR)
55dB
Quiescent Current
150uA
RoHS Compliant
Yes
Width
1.6mm
Compliance
RoHS
Compliant
Datasheet
Microchip MIC5318-3.3YD5-TR Datasheet
Download the complete datasheet for Microchip MIC5318-3.3YD5-TR to view detailed technical specifications.
