8-bit RISC microcontroller featuring 4MHz clock speed and 1.5KB FLASH memory. This surface mount device offers 5 I/O pins, an 8-bit address and data bus, and an internal oscillator. Operating from 2V to 5.5V, it includes POR and WDT peripherals, with a maximum operating temperature of 85°C. Interface options include RS-232 and USB.
Frequency4MHz
PackageSOIC
Current175uA
MountingSurface Mount
Quick Jump:
Technical Specifications
Microchip PIC12F509-I/SN technical specifications.
General
Access Time
4us
Address Bus Width
8b
Package/Case
SOIC
Core Architecture
PIC
Data Bus Width
8b
Frequency
4MHz
Height
1.5mm
Interface
RS-232, USB
Lead Free
Lead Free
Length
4.9mm
Max Frequency
4MHz
Max Operating Temperature
85°C
Max Power Dissipation
800mW
Max Supply Voltage
5.5V
Memory Size
1.5KB
Memory Type
FLASH,
Min Operating Temperature
-40°C
Min Supply Voltage
2V
Mount
Surface Mount
Number of Bits
8
Number of I/Os
5
Number of Programmable I/O
6
Number of Timers/Counters
1
Oscillator Type
Internal
Package Quantity
100
Packaging
Rail/Tube
Peripherals
POR, WDT
Radiation Hardening
No
RAM Size
41B
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
PIC® 12F
Supply Current
175uA
Watchdog Timer
Yes
Width
3.9mm
Compliance
RoHS
Compliant
Datasheet
Microchip PIC12F509-I/SN Datasheet
Download the complete datasheet for Microchip PIC12F509-I/SN to view detailed technical specifications.
