8-bit RISC microcontroller featuring a 33MHz core speed and 32KB OTP memory. This integrated circuit offers 50 programmable I/O pins, 12 ADC channels, and 3 PWM channels. Interfaces include I2C, SPI, RS-232, USART, SCI, and UART. Operating voltage ranges from 4.5V to 5.5V, with an operating temperature range of -40°C to 85°C. The component is housed in a PLCC package and is RoHS compliant.
Frequency33MHz
PackagePLCC
Quick Jump:
Technical Specifications
Microchip PIC17C756A-33I/L technical specifications.
General
| Access Time | 33us |
| Package/Case | PLCC |
| Core Architecture | PIC |
| Data Bus Width | 8b |
| Frequency | 33MHz |
| Height | 3.68mm |
| Interface | I2C, SPI, RS-232, USART, SCI, UART, SSP |
| Lead Free | Lead Free |
| Length | 24.33mm |
| Max Frequency | 33MHz |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Max Power Dissipation | 1W |
| Max Supply Voltage | 5.5V |
| Memory Size | 32KB |
| Memory Type | OTP |
| Min Supply Voltage | 4.5V |
| Number of ADC Channels | 12 |
| Number of Bits | 8 |
| Number of I/Os | 50 |
| Number of I2C Channels | 1 |
| Number of Programmable I/O | 50 |
| Number of PWM Channels | 3 |
| Number of SPI Channels | 1 |
| Number of Timers/Counters | 4 |
| Operating Supply Voltage | 5V |
| Oscillator Type | External |
| Package Quantity | 19 |
| Packaging | Rail/Tube |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT, I2C |
| Radiation Hardening | No |
| RAM Size | 902B |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | PIC® 17C |
| Watchdog Timer | Yes |
| Width | 24.33mm |
Compliance
| RoHS | Compliant |
Datasheet
Microchip PIC17C756A-33I/L Datasheet
Download the complete datasheet for Microchip PIC17C756A-33I/L to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
