PIC18F24K20-I/SO

Datasheet

8-Bit 64MHz PIC MCU, 16KB Flash, SOIC-28, 25 I/O

Microchip

PIC18F24K20-I/SO

Name: PIC18F24K20-I/SO Microchip
Brand: Microchip
SKU: PIC18F24K20-I/SO

8-Bit 64MHz PIC MCU, 16KB Flash, SOIC-28, 25 I/O

8-bit FLASH microcontroller featuring an 8b data bus width and a 64MHz core frequency. This surface mount device offers 16KB of FLASH memory, 768B of RAM, and operates from 1.8V to 3.6V. Integrated peripherals include I2C, SPI, and UART interfaces, 11 ADC channels, 5 PWM channels, and 4 timers/counters. Packaged in a 7.50mm width SOIC-28, this lead-free component supports a maximum operating temperature of 85°C.

Frequency64MHz

PackageSOIC

MountingSurface Mount

Quick Jump:

Chat with Datasheet

Technical Specifications

Microchip PIC18F24K20-I/SO technical specifications.

General

Package/Case	SOIC
Core Architecture	PIC
Data Bus Width	8b
Density	16KB
Frequency	64MHz
Height	2.35mm
Interface	I2C, SPI, UART, USART
Lead Free	Lead Free
Length	17.9mm
Max Frequency	64MHz
Max Operating Temperature	85°C
Memory Size	16KB
Memory Type	FLASH,
Min Operating Temperature	-40°C
Max Power Dissipation	1W
Max Supply Voltage	3.6V
Min Supply Voltage	1.8V
Mount	Surface Mount
Number of ADC Channels	11
Number of I/Os	25
Number of I2C Channels	1
Number of Programmable I/O	25
Number of PWM Channels	5
Number of SPI Channels	1
Number of Timers/Counters	4
Operating Supply Voltage	3V
Oscillator Type	Internal
Package Quantity	27
Packaging	Rail/Tube
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT, HLVD, I2C
Radiation Hardening	No
RAM Size	768B
Reach SVHC Compliant	No
RoHS Compliant	Yes
Termination	SMD/SMT
Watchdog Timer	Yes
Width	7.5mm
