Technical Specifications
Microchip PIC32MX664F128H-V/PT technical specifications.
General
Package/Case
TQFP
Data Bus Width
32b
Interface
I2C, SPI, USB, Ethernet, UART, USART
Max Frequency
25MHz
Max Operating Temperature
105°C
Memory Size
128KB
Memory Type
FLASH,
Min Operating Temperature
-40°C
Number of I/Os
53
Number of UART Channels
6
Operating Supply Voltage
3.6V
Oscillator Type
Internal
Package Quantity
160
Packaging
Tray
Peripherals
Brown-out Detect/Reset, POR, PWM, WDT, DMA
RAM Size
32KB
RoHS Compliant
Yes
Series
PIC® 32MX
Compliance
RoHS
Compliant
Datasheet
Microchip PIC32MX664F128H-V/PT Datasheet
Download the complete datasheet for Microchip PIC32MX664F128H-V/PT to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
