PackagePDIP
Current1mA
MountingThrough Hole
Power730mW
Quick Jump:
Technical Specifications
Microchip TC1412NCPA technical specifications.
General
Package/Case
PDIP
Channel Type
Single
Fall Time
26ns
Lead Free
Lead Free
Max Operating Temperature
70°C
Min Operating Temperature
0°C
Max Output Current
2A
Max Power Dissipation
730mW
Max Supply Voltage
16V
Min Supply Voltage
4.5V
Mount
Through Hole
Number of Drivers
1
Number of Outputs
1
Package Quantity
60
Packaging
Rail/Tube
Power Dissipation
730mW
Propagation Delay
45ns
RoHS Compliant
Yes
Supply Current
1mA
Compliance
RoHS
Compliant
Datasheet
Microchip TC1412NCPA Datasheet
Download the complete datasheet for Microchip TC1412NCPA to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
