12-bit, 1-channel dual-slope analog-to-digital converter (ADC) featuring parallel and serial interface options. This integrated circuit offers bipolar input polarity and a dual supply voltage of 5V, with an operating supply voltage of 6.2V. Designed for surface mount applications, it operates within a temperature range of 0°C to 70°C and has a maximum power dissipation of 1.23W. The component is RoHS compliant and lead-free, packaged in a PLCC format.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Microchip TC7109CLW datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | PLCC |
| Conversion Rate | 0.01KS/s |
| Dual Supply Voltage | 5V |
| Input Type | DIFFERENTIAL |
| Interface | Parallel, Serial |
| Lead Free | Lead Free |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | 0°C |
| Max Power Dissipation | 1.23W |
| Mount | Surface Mount |
| Nominal Supply Current | 700uA |
| Number of Analog Inputs | 1 |
| Number of Bits | 12 |
| Number of Channels | 1 |
| Number of Converters | 1 |
| Number of Elements | 1 |
| Operating Supply Voltage | 6.2V |
| Output Voltage | 300mV |
| Package Quantity | 27 |
| Packaging | Rail/Tube |
| Polarity | Bipolar |
| Power Dissipation | 1.23W |
| Resolution | 12b |
| RoHS Compliant | Yes |
| Sampling Rate | 10S/s |
| Supply Type | Dual |
| RoHS | Compliant |
