N-channel JFET for small signal applications, featuring a 630mA continuous drain current and 40V drain-to-source breakdown voltage. This surface-mount component, housed in a SOT-89 package, offers a low 2 Ohm drain-to-source resistance and fast switching times with turn-on delay of 3ns and fall time of 7ns. It operates across a wide temperature range of -55°C to 150°C with a maximum power dissipation of 1.6W.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Microchip TN0104N8-G datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | SOT-89 |
| Continuous Drain Current (ID) | 630mA |
| Drain to Source Breakdown Voltage | 40V |
| Drain to Source Resistance | 2R |
| Fall Time | 7ns |
| Gate to Source Voltage (Vgs) | 20V |
| Height | 1.6mm |
| Input Capacitance | 70pF |
| Length | 4.6mm |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -55°C |
| Max Power Dissipation | 1.6W |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Package Quantity | 2000 |
| Packaging | Tape and Reel |
| Polarity | N-CHANNEL |
| Power Dissipation | 1.6W |
| Radiation Hardening | No |
| Rds On Max | 2R |
| Turn-Off Delay Time | 6ns |
| Turn-On Delay Time | 3ns |
| Weight | 0.001862oz |
| Width | 2.6mm |
| RoHS | Compliant |
