2-port USB 2.0 hub controller IC, supporting 480Mbps data rates. Features I2C, USB, and SMBus interfaces with integrated ESD protection. Operates from a 3V to 3.6V supply, with a typical 3.3V operating voltage and 70mA current. Packaged in a 4.1mm x 4.1mm x 0.95mm QFN surface-mount package, suitable for automotive applications with an operating temperature range of -40°C to 85°C. RoHS compliant.
PackageQFN
MountingSurface Mount
Quick Jump:
Technical Specifications
Microchip USB2422-I/MJ technical specifications.
General
Package/Case
QFN
Data Rate
480Mbps
ESD Protection
Yes
Height
0.95mm
Interface
I2C, USB, SMBus
Lead Free
Lead Free
Length
4.1mm
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Max Supply Voltage
3.6V
Min Supply Voltage
3V
Mount
Surface Mount
Number of Channels
2
Number of Ports
2
Number of Transceivers
1
Operating Supply Current
70mA
Operating Supply Voltage
3.3V
Package Quantity
490
Packaging
Tray
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Width
4.1mm
Compliance
RoHS
Compliant
Datasheet
Microchip USB2422-I/MJ Datasheet
Download the complete datasheet for Microchip USB2422-I/MJ to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
